Features:

Stripping
- No scratches from heated stripping
- Stripping time : 1.5sec
- Over 5kg/f Tensile Strength of fiber after stripping
Cleaning
- One-touch pump
- Easy to refill cleaning alcohol
Cleaving
- Single-action cleaving
- Fiber chip collector attached
Resistance to Shock, Dust and Water
- The splicer with high reliability has stable performance even in a harsh environment.
- Shock – Free Fall : 76cm from 5 sides l Waterproof : IPx2 l Dustproof : IP5x
Compatible with Fusion Splice-On Connector(SOC) in accordance with the Industrial Standard

Specifications:

Fiber alignment	Active Clad to Clad Alignment
Applicable type of fibers	0.25mm, 0.9mm, 2.0mm, 3.0mm Indoor cable
Fiber Count	Single fiber
Applicable fiber dimensions	Cladding diameter : 125?, Coating diameter : 150?~3mm
Fiber setting and cleaved length	5mm to 16mm
Splicing modes	Splice mode: 300, Heater mode: 100
Typical Splice Loss	SM: 0.02dB, MM: 0.01dB, DS: 0.04dB, NZDS: 0.04dB
Return loss	> 60dB
Splicing time	Typical 7sec (with SM)
Splice loss estimate	Available
Sleeve heating time	Typical 13sec, IS-60 mode with IS-20 sleeve
Applicable protection sleeve	40mm, 60mm and Micro sleeve
Storage of splice result	Data : Up to 5,000 (Image : Up to 5,000 pcs)
Tension test	1.96N to 2.25N
Operating condition	Altitude: 0~5,000m above sea level, Temperature: -10?~50?, Humidity: 0~95%, Wind: 15m/s, non-condensing, dust proof, water proof, shock proof
Storage condition	Temperature: -40?~80?, Humidity: 0~95%
Dimension	Dimension
Weight	1.5kg (Including battery)
Viewing method and display	2AXIS Two CMOS cameras and 4.3-inch color LCD monitor
Fiber view and magnification	X/Y : 130X, Max : 260X
Power supply	DC Lithium polymer battery(DC 14.8V, 1650mAh?2), 100 ~ 240V AC Adapter
No. of splice cycles with battery	Typical 200 cycles
Electrode lifetime	More than 21,000 times
Blade lifetime	75,000 fibers
Terminals	USB
