תיאור מוצר
- נתונים טכניים
- MONO or POLY
MONO
Maximum power (Wp)
3.2W
Maximum power voltage (V)
6V (+3%)
Maximum power current (A)
534mA (+3%)
Open circuit voltage (V)
7.2V (+3%)
Short circuit current (A)
566mA (+3%)
Number of cells (Pcs)
12PCS
Size of module (mm)
174x121x12mm (+/-0.2mm)
Maximum system voltage (V)
600V
Temperature Range
-40°C～+85°C
PCB
1.2mm
Encapsulant
EVA
Back (PET)
0.2mm PET
Cell Efficiency (%)
>19.6%
Output tolerance (%)
+3%
Standard Test Conditions
Tungsten halogen lamp illumination 38000lux
