מחירון Uniview 2023
Network Video Input: 32-ch
Bandwidth Requirement: 160Mbps
OUTPUT
HDMI Output: 2-ch, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz. (HDMI supports Audio Output)
VGA Output: 2-ch, Resolution: 1920×1080/60Hz, 1920×1080/50Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz.
Dual Stream: Support
Recording Resolution: 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/D1/CIF/QCIF
Synchronous Preview/Playback: 4*(30fps @8MP), 6*(8fps @5MP), 8*(20fps @4MP), 10*(20fps @3MP), 16*(30fps @1080P), 32*(30fps @720P)
FORMAT
Video Format: H.265(HEVC)/H.264
Audio Format: G.711 U-Law
STORAGE
Drivers: 8 SATA HDD (3.5”)
External Storage: 1 eSATA
Capacity: Up to 6TB capacity for each HDD
RECORD
Synchronous Recording: 32*5MP
Recording Type: Manual recording, Timing recording, Motion detection recording, Alarm recording, Motion detection or alarm recording, Motion detection and alarm recording
Snapshot: Manual Snapshot
Playback: Video playback, Image playback
Backup: Video backup, Image backup
NETWORK
Network Protocols: IPv4, HTTP, NTP, SMTP, PPPoE, DDNS etc
INTERFACE
Network Interface: 2 RJ45 100M/1000M
USB Interface: 1*USB 3.0; 2*USB 2.0
Serial Interface: 1 RS-485 Series port for PTZ, 1 RS-232 Series port for Console, 1 RS-485 Series port for Keyboard
Audio Input/Output: 1*RCA/2*RCA
Alarm Input: 16-ch
Alarm Output: 4-ch
GENERAL
Power Supply: AC 100-240V 50Hz-60Hz
Consumption(without HDD): ≤35W
Working Conditions: Temperature:-10℃~+55℃ Humidity:10%~90%
Dimensions: 440mm(W)×420mm(D)×88.2mm(H), 2.0U Standard Chassis
Weight: 6.0Kg
Warranty: 2 years
