SH-8100A5N-2L(MM)

• Video:

Input: 8CH Standard BNC + 2CH IP (Over Network)

Output: HDMI(1920×1080), VGA (1280×1024, 1024×768)



• Recording:

IP: 5MP and lower: 30/25FPS Per Channel

AHD: 2MP lite / 1MP: Up to 15/12FPS Per Channel

TVI: 2MP lite / 1MP: Up to 15/12FPS Per Channel

CVI: 2MP lite / 1MP: Up to 15/12FPS Per Channel

CVBS: 960H: Up to 30/25FPS Per Channel



• Playback:

8 Channel Simultaneously (Local)

4 Channel Simultaneously (Remote)



• Analytics:

For AHD Cameras Line Crossing (No Direction Choice), Sterile Area, Smart Search

For IP Cameras Line Crossing (With Direction Choice), Sterile Area, Item Monitoring, Camera Tampering, Smart Search



• Bandwidth:

Incoming: 16Mbps

Outgoing: 60Mbps

• Audio:

Input: 1 Channel (RCA) + IP Camera inputs

Output: 1 Channel (RCA) + IP Camera outputs

2 Way audio



• Storage:

1 x SATA (Up to 6TB)



• USB Port:

2 x USB2.0



• Network:

RJ-45: 100Mbps



• Alarm:

Input: IP Cameras inputs only

Output: IP Cameras outputs only



• PTZ / Keyboard:

Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
